Build Process
Most aspects of the build process are covered in my video here
Bill of Materials
To build this guitar you will need to CNC machine the body, neck, backplates, and input jack plate. The recommended tooling is outlined below.
| Tool | Shank Diameter | Cutting Diameter | Cutting Length |
|---|---|---|---|
| Upcut Router Bit/Endmill | 1/4" | 1/4" | 1" |
| Upcut Router Bit/Endmill | 1/4" | 1/4" | 2" |
| Upcut Ball-nose Router Bit/Endmill | 1/4" | 1/4" | 1" |
| Upcut Router Bit/Endmill | 1/8" | 1/8" | 1" |
| Upcut Router Bit/Endmill | 0.6 mm | 1/8" | 1" |
